HITACHI wirnik 360853 WH18DSL
Hitachi -wirnik.
Pozycja na schemacie nr 26
Nr katalogowy : 360853
Zastosowanie: WH18DSL
| 1 | 315984 | RETAINING RING |
| 2 | 315983 | WASHER (D) |
| 3 | 321657 | GUIDE SPRING (A) (OLD 322716) |
| 4 | 322717 | GUIDE SLEEVE (D) |
| 5 | 327766 | FRONT CAP (F) |
| 6 | 327765 | PROTECTOR (J) |
| 7 | 327003 | HAMMER CASE |
| 8 | 319535 | STEEL BALL D3.5 (1 PCS) |
| 9 | 329709 | ANVIL (D) |
| 10 | 959154 | STEEL BALL D5.556 (10 PCS) (OLD 939277Z) |
| 11 | 326789 | HAMMER (F) (OLD 321656) |
| 12 | 959148 | STEEL BALL D3.175 (10 PCS) |
| 13 | 315978 | WASHER (J) |
| 14 | 321660 | HAMMER SPRING (D) |
| 15 | 316172 | WASHER (S) |
| 16 | 316171 | STOPPER |
| 17 | 321666 | SPINDLE (D) |
| 18 | 326295 | IDLE GEAR SET (2 PCS) |
| 19 | 319914 | NEEDLE ROLLER |
| 20 | 326787 | RING GEAR (E) |
| 21 | 983852 | O-RING (S-42) |
| 22 | 319911 | WASHER (E) |
| 23 | 323118 | BALL BEARING 6901VV-N |
| 24 | 319909 | DAMPER |
| 25 | 326786 | INNER COVER (D) |
| 26 | 360853 | ARMATURE ASS'Y |
| 27 | 323327 | SIDE YOKE (OLD 321659) |
| 28 | 322744 | MAGNET (D) |
| 29 | 324828 | YOKE (A) |
| 30 | 324830 | DUST GUARD FIN (C) |
| 31 | 321662 | BRUSH BLOCK (OLD 320376) |
| 32 | 999100 | CARBON BRUSH (1 PAIR) |
| 33 | 319918 | BRUSH CAP |
| 34 | 301653 | TAPPING SCREW D4X20 (W/FLANGE) BLACK (OLD 305095) |
| 35 | 330102 | HOUSING SET (A+B) (GREEN) |
| 36 | 326782 | LEVER (C) |
| 37 | 994532 | MACHINE SCREW (W/SP.WASHER) M3X5 |
| 38 | 321661 | PUSHING BUTTON (A) |
| 40 | 326783 | LEVER (B) |
| 41 | 326790 | HOOK (A) |
| 42 | 327001 | TRUSS HD. SCREW M4 (BLACK) |
| 43 | 327002 | LOCK NUT M4 (BLACK) |
| 44 | 327004 | PACKING |
| 46 | 330084 | CONTROLLER |
| 47 | 330083 | SWITCH ASS'Y (OLD 330099) |
| 49 | 306952 | STRAP (BLACK) (OLD 317320) |
| 501 | 329897 | BATTERY COVER |
| 506 | 324090 | HANDLE (DARK GREY) |
| 602 | 309922 | GREASE FOR IMPACT DRIVER (500 G) |
