Hilti części zamienne do młota udarowego 26264 TE 805
Spis części zamiennych do młota 26264 TE 805
Przy zapytaniu o dostępność i cenę prosimy podać pozycję
na schemacie lub nr katalogowy części.
| Pozycja na schemacie | Nr katalogowy | Nazwa Części |
| 1 | 234286 | housing |
| 2 | 26299 | cylinder assy |
| 3 | 26327 | guide sleeve |
| 4 | 234241 | chuck body |
| 5 | 234281 | drive piston |
| 6 | 206035 | plastite screw 45 5X60 |
| 7 | 26398 | rotor 110/120V assy |
| 8 | 26343 | stator 110/120V |
| 9 | 74738 | transducer assy |
| 11 | 234284 | conrod |
| 12 | 234282 | piston pin |
| 13 | 234245 | motor housing endcap assy |
| 14 | 74588 | rpm regulator 100/115V |
| 15 | 17878 | supply cord USA/CDN |
| 16 | 26294 | insulating unit |
| 17 | 26248 | flexible conductor assy |
| 18 | 26323 | flexible conductor assy |
| 19 | 26347 | holder assy |
| 20 | 26375 | grip unit |
| 21 | 234256 | ram |
| 22 | 234235 | seal.ring |
| 23 | 13724 | housing endcap |
| 24 | 26253 | absorber |
| 25 | 13898 | grip |
| 26 | 17904 | switch |
| 27 | 13727 | nut |
| 28 | 13771 | o-ring 71,44X3,53 |
| 29 | 13728 | crankshaft |
| 30 | 13763 | cover assy |
| 31 | 234248 | striker piston |
| 32 | 13772 | o-ring 31,34X3,53 |
| 33 | 26256 | ring |
| 34 | 234059 | cap |
| 35 | 234019 | retaining ring |
| 37 | 234061 | cover |
| 38 | 234063 | absorber ring |
| 39 | 234238 | lock |
| 40 | 234026 | ball 15 III |
| 41 | 234237 | sleeve |
| 42 | 234058 | compression spring |
| 43 | 26351 | retaining ring SP 52 |
| 44 | 26257 | guard sleeve |
| 45 | 26247 | o-ring 58X2 |
| 46 | 49175 | o-ring 55X2.5 |
| 47 | 13790 | ball 6 |
| 48 | 26274 | chiselling handle assy |
| 49 | 26354 | chiselling handle clam assy |
| 50 | 26355 | chiselling handle clam |
| 51 | 234210 | clevis pin |
| 52 | 208268 | circlip 6X0,7 |
| 55 | 233548 | hexagon bolt M8X160 |
| 56 | 233547 | snap-lock ring 1 |
| 57 | 233549 | knob assy |
| 59 | 26369 | torx-soc.cap screw M5X25 |
| 62 | 74161 | ball bearing 6201 |
| 63 | 13777 | ball bearing 6203-2RS/VT245 |
| 64 | 234270 | rotary shaft seal B15X25X5 |
| 66 | 26370 | torx-soc.cap screw M5X80 |
| 67 | 17979 | hex nut M8 LH |
| 68 | 26372 | torx-soc.tapt.scr. M5X20 |
| 69 | 26368 | torx-s.h.s. M5X12 |
| 70 | 71468 | circlip 32X1,2 |
| 72 | 233637 | torx-rec.ov.screw M6X25 10.9 |
| 73 | 26367 | torx-rec.ov.screw M4X16 |
| 74 | 66299 | washer 10,5 |
| 76 | 13960 | cover |
| 78 | 70428 | ball bearing |
| 81 | 71483 | conductor end A1-6 |
| 82 | 201495 | torx-soc.tapt.scr. M3,5X5,5 |
| 83 | 75094 | supp.co.cl. |
| 85 | 72402 | protective sleeve |
| 87 | 207960 | torx-soc.re.scr 4X18 |
| 88 | 234195 | retaining ring |
| 89 | 234197 | o-ring 42X2,5 |
| 90 | 70123 | roller |
| 91 | 234193 | washer |
| 92 | 234196 | o-ring 42X6 |
| 93 | 74238 | circlip 26X1,2 |
| 94 | 74719 | brush holder assy |
| 95 | 74718 | carbon brush |
| 98 | 26358 | torx-soc.re.scr 3X16 |
| 102 | 26365 | torx-rec.ov.screw M6X16 |
| 106 | 74729 | cooling fan assy |
| 111 | 74722 | labyrinth seal |
| 116 | 9357 | supporting washer S12X18 |
| 118 | 26284 | rating plate TE805 120V USA |
| 119 | 234199 | ball bearing 15X35X11 |
| 120 | 26389 | labyrinth seal |
| 121 | 26348 | connector housing assy |
| 122 | 26352 | torx-soc.re.scr 3X25 |
| 124 | 26373 | torx-soc.re.scr 4X30 |
| 125 | 26374 | grip unit |
| 126 | 234081 | seal |
| 127 | 234082 | o-ring 25X3.53 FKM |
| 128 | 26298 | seal.ring NATUR |
| 128 | 234275 | seal.ring GRAU |
| 703 | 30215 | oil TURMOPO.20HD 1L |
| 810 | 30214 | grease Molykote TP42 100GR |
| 900 | 59299 | loctite 222 250CCM |
| 901 | 3994 | loctite 243 50CCM |
