Hitachi H45MR wszystkie części zamienne nowe i używane
Hitachi H45MR wszystkie części zamienne nowe i używane
-prosimy pytać.
| ITEM NO. | CODE NO. | DESCRIPTION | NO. USED |
| 1 | 315-529 | FRONT CAP | 1 |
| 2 | 320-802 | GRIP (A) | 1 |
| 3 | 320-803 | RING | 2 |
| 4 | 320-804 | NEEDLE HOLDER | 1 |
| 5 | 313-421 | NEEDLE ROLLER D8X20 | 2 |
| 6 | 320-806 | SPRING (A) | 1 |
| 7 | 317-088 | RETAINING RING D42 | 2 |
| 8 | 320-810 | BALL HOLDER | 1 |
| 9 | 320-807 | GRIP (B) | 1 |
| 10 | 320-808 | GRIP (C) | 1 |
| 11 | 959-150 | STEEL BALL D6.35 (10 PCS.) | 4 |
| 12 | 981-942 | SEAL LOCK HEX. SOCKET HD. BOLT M6X25 | 4 |
| 13 | 320-809 | FRONT COVER | 1 |
| 14 | 980-879 | O-RING (S-34) | 1 |
| 15 | 990-067 | O-RING (1AS-50) | 1 |
| 16 | 320-805 | RETAINER SLEEVE | 1 |
| 17 | 320-812 | DAMPER (A) | 1 |
| 18 | 320-811 | HAMMER HOLDER (A) | 1 |
| 19 | 319-572 | O-RING (S-25) | 1 |
| 20 | 320-813 | SECOND HAMMER | 1 |
| 21 | 320-817 | DAMPER (C) | 1 |
| 22 | 320-814 | HAMMER HOLDER (B) | 1 |
| 23 | 320-815 | DAMPER (B) | 1 |
| 24 | 320-835 | WASHER | 1 |
| 25 | 320-816 | HAMMER HOLDER (C) | 1 |
| 26 | 320-822 | STRIKER | 1 |
| 27 | 320-823 | O-RING | 2 |
| 28 | 320-818 | CYLINDER HOLDER | 1 |
| 29 | 320-820 | SLEEVE (A) | 1 |
| 30 | 320-821 | SPRING (C) | 1 |
| 31 | 320-819 | CYLINDER | 1 |
| 32 | 320-826 | PISTON PIN | 1 |
| 33 | 320-824 | PISTON | 1 |
| 34 | 320-825 | CONNECTING ROD | 1 |
| 35 | 986-940 | SEAL LOCK HEX. SOCKET HD. BOLT M6X45 | 4 |
| 36 | 983-162 | SEAL LOCK HEX. SOCKET HD. BOLT M4X12 | 4 |
| 37 | HITACHI LABEL | 1 | |
| 38 | 320-831 | CRANK COVER | 1 |
| 39 | HITACHI LABEL | 1 | |
| 40 | 956-996 | O-RING (1AS-60) | 1 |
| 41 | 939-540 | RETAINING RING FOR D10 SHAFT (10 PCS.) | 1 |
| 42 | 320-829 | CRANK SHAFT | 1 |
| 43 | 930-511 | FEATHER KEY 4X4X10 | 1 |
| 44 | 980-760 | SEAL LOCK HEX.SOCKET FLAT HD. BOLT M5X12 | 2 |
| 45 | 980-761 | BEARING COVER (A) | 1 |
| 46 | 620-3DD | BALL BEARING 6203DDCMPS2L | 1 |
| 47 | 310-119 | OIL SEAL | 1 |
| 48 | 320-828 | CYLINDER CRANK CASE | 1 |
| 49 | NAME PLATE | 1 | |
| 50 | 320-837 | HANDLE PACKING (A) | 1 |
| 51 | 310-124 | HANDLE DAMPER | 8 |
| 52 | 310-123 | TRANSATORY UNIT | 2 |
| 53 | 320-830 | FIRST GEAR | 1 |
| 54 | 939-299 | NEEDLE BEARING (M661) | 1 |
| 55 | 320-841 | GEAR COVER ASS'Y | 1 |
| 56 | 317-107 | BOLT M8 | 1 |
| 57 | 317-106 | HANDLE HOLDER (B) | 2 |
| 58 | 317-105 | HANDLE HOLDER (A) | 2 |
| 59 | 320-635 | BAND | 1 |
| 60 | 317-108 | GRIP | 1 |
| 61 | 317-103 | SIDE HANDLE ASS'Y | 1 |
| 62 | 935-829 | BRUSH CAP | 2 |
| 63 | 999-073 | CARBON BRUSH (AUTO STOP TYPE) (1 PAIR) | 2 |
| 64 | 971-001 | BRUSH HOLDER | 2 |
| 65 | 938-477 | HEX. SOCKET SET SCREW M5X8 | 2 |
| 66 | 320-834 | TAIL COVER | 1 |
| 67 | 877-839 | SEAL LOCK HEX. SOCKET HD. BOLT M5X10 | 2 |
| 68 | 620-1DD | BALL BEARING 6201DDCMPS2L | 1 |
| 69 | 302-429 | DUST WASHER (B) | 1 |
| 70 | 360-571C | ARMATURE 110V | 1 |
| 70 | 360-571U | ARMATURE ASS'Y 120V | 1 |
| 70 | 360-571E | ARMATURE 220V-230V | 1 |
| 70 | 360-571F | ARMATURE 240V | 1 |
| 71 | 320-832 | FAN GUIDE | 1 |
| 72 | 953-174 | HEX. HD. TAPPING SCREW D5X55 | 2 |
| 73 | 340-519C | STATOR ASS'Y 110V | 1 |
| 73 | 340-519G | STATOR ASS'Y 120V | 1 |
| 73 | 340-519H | STATOR ASS'Y 220V-230V | 1 |
| 73 | 340-519E | STATOR ASS'Y 220V-230V | 1 |
| 73 | 340-519F | STATOR ASS'Y 240V | 1 |
| 74 | 930-703 | BRUSH TERMINAL | 2 |
| 75 | 930-804 | TERMINAL M4.0 (10 PCS.) | 1 |
| 76 | 982-631 | WASHER (A) | 1 |
| 77 | 608-VVM | BALL BEARING 608VVC2PS2L | 1 |
| 78 | 320-833 | HOUSING ASS'Y | 1 |
| 79 | 320-836 | SLEEVE (B) | 1 |
| 80 | 320-838 | HANDLE PACKING (B) | 1 |
| 81 | 984-509 | SEAL LOCK HEX. SOCKET HD. BOLT M5X14 | 2 |
| 82 | 980-754 | INTERNAL WIRE HOLDER | 1 |
| 82 | 310-424 | INTERNAL WIRE HOLDER | 1 |
| 83 | 991-690 | SEAL LOCK HEX. SOCKET HD. BOLT M5X12 | 4 |
| 84 | 991-711 | DISTANCE PIECE (B) | 4 |
| 85 | 320-839 | HANDLE (A) | 1 |
| 86 | 990-861 | INTERNAL WIRE | 1 |
| 87 | 994-273 | NOISE SUPPRESSOR | 1 |
| 88 | 317-492 | SUPPORT (B) | 1 |
| 89 | 981-974 | INTERNAL WIRE | 1 |
| 90 | VINYL TUBE | 2 | |
| 91 | 306-143 | SWITCH (B) (1P SCREW TYPE) W/LOCK | 1 |
| 92 | 320-840 | HANDLE (B) | 1 |
| 93 | 307-028 | TAPPING SCREW (W/FLANGE) D4X25 (BLACK) | 3 |
| 94 | 959-140 | CONNECTOR 50091 (10 PCS.) | 1 |
| 95 | 938-307 | PILLAR TERMINAL | 1 |
| 96 | 959-141 | CONNECTOR 50092 (10 PCS.) | 1 |
| 97 | SDS MAX LABEL | 1 | |
| 98 | 984-750 | TAPPING SCREW (W/FLANGE) D4X16 | 2 |
| 99 | 960-266 | CORD CLIP | 1 |
| 99 | 981-987Z | CORD CLIP | 1 |
| 100 | 949-423 | WASHER M4 (10 PCS.) | 1 |
| 101 | 981-373 | TUBE (D) | 2 |
| 102 | 980-063 | TERMINAL | 1 |
| 102 | 992-810 | TERMINAL | 1 |
| 102 | 930-804 | TERMINAL M4.0 (10 PCS.) | 1 |
| 103 | 953-327 | CORD ARMOR D8.8 | 1 |
| 103 | 938-051 | CORD ARMOR D10.1 | 1 |
| 104 | 500-394Z | CORD | 1 |
| 104 | 500-408Z | CORD | 1 |
| 104 | 500-446Z | CORD | 1 |
| 104 | 500-454Z | CORD | 1 |
| 104 | 500-390Z | CORD | 1 |
| 104 | 500-391Z | CORD | 1 |
| 104 | 500-434Z | CORD | 1 |
